Building MCP Servers with TypeScript: Zero to Deploy Tutorial

Step-by-step guide to building MCP servers with TypeScript. Learn to create tools, resources, and prompts using the MCP SDK v2, test with Claude Code, debug common issues, and publish to npm.

Bruce

MCPTypeScriptClaude CodeAI AgentTutorial

AI Guides

2437 Words

2026-03-02 02:00 +0000

Building MCP servers with TypeScript from zero to deploy

MCP (Model Context Protocol) is the standard way to give AI models access to external tools, data, and services in 2026. If you’ve used Claude Code or Cursor, you’ve already used MCP servers — they power everything from database queries to API integrations.

This tutorial walks you through building your own MCP server from scratch with TypeScript, from project setup to npm publishing. By the end, you’ll have a working server that any MCP-compatible AI client can use.

What Is MCP? The 30-Second Version

MCP is USB-C for AI. Just as USB-C lets your laptop connect to monitors, drives, and keyboards through one standard port, MCP lets AI models connect to databases, APIs, and file systems through one standard protocol. The official MCP specification defines the full protocol details.

┌─────────────────────────────────────────────┐
│           MCP Client (Host)                 │
│   Claude Code / Cursor / VS Code Copilot    │
├─────────────────────────────────────────────┤
│           MCP Protocol Layer                │
│         JSON-RPC 2.0 + STDIO/HTTP           │
├─────────────────────────────────────────────┤
│           MCP Server (Your Code)            │
│   Tools / Resources / Prompt Templates      │
└─────────────────────────────────────────────┘

An MCP server exposes three types of capabilities:

CapabilityWhat It DoesExamples
ToolsLet AI perform actionsQuery a database, send a message, call an API
ResourcesLet AI read dataConfiguration files, user profiles, logs
PromptsPre-built interaction templatesCode review template, summary template

Tools are the most common — and the focus of this tutorial.

For a broader overview of the MCP protocol, see my MCP Protocol Explained guide.

Why Build MCP Servers with Claude Code

You can build MCP servers with any editor, but Claude Code is uniquely suited for this:

  1. Claude Code is an MCP client. Run claude mcp add and test your server instantly — no separate client setup needed.
  2. Live testing loop. Write a tool, register it, and ask Claude to call it. Debug in real-time.
  3. AI building AI tools. Using Claude Code to write MCP server code is AI developing its own plugins. The efficiency is remarkable.

Prerequisites

DependencyMinimum VersionCheck Command
Node.js>= 18node -v
npm>= 9npm -v
TypeScript>= 5.0npx tsc --version
Claude CodeLatestclaude --version

Tutorial: Build a Weather MCP Server

We’ll start with a classic example — a weather query tool. It covers the complete MCP server development workflow: project init, tool registration, testing, and debugging.

Step 1: Initialize the Project

mkdir weather-mcp-server
cd weather-mcp-server
npm init -y

Install dependencies:

npm install @modelcontextprotocol/server zod
npm install -D typescript @types/node

Two core packages:

  • @modelcontextprotocol/server — MCP Server SDK providing McpServer, StdioServerTransport, and related classes
  • zod — Schema validation library used by SDK v2 to define tool input/output formats

Create tsconfig.json:

{
  "compilerOptions": {
    "target": "ES2022",
    "module": "Node16",
    "moduleResolution": "Node16",
    "outDir": "./dist",
    "rootDir": "./src",
    "strict": true,
    "esModuleInterop": true,
    "skipLibCheck": true,
    "declaration": true
  },
  "include": ["src/**/*"]
}

Update package.json with required fields:

{
  "name": "weather-mcp-server",
  "version": "1.0.0",
  "type": "module",
  "bin": {
    "weather-mcp-server": "./dist/index.js"
  },
  "scripts": {
    "build": "tsc",
    "start": "node dist/index.js"
  }
}

Critical: "type": "module" is required. The MCP SDK uses ESM modules.

Step 2: Write the MCP Server

Create src/index.ts — the entry point for your server:

#!/usr/bin/env node

import { McpServer } from "@modelcontextprotocol/server";
import { StdioServerTransport } from "@modelcontextprotocol/server";
import * as z from "zod";

// 1. Create the server instance
const server = new McpServer({
  name: "weather-server",
  version: "1.0.0",
});

// 2. Simulated weather data (replace with real API in production)
function getWeatherData(city: string) {
  const weatherMap: Record<
    string,
    { temperature: number; condition: string; humidity: number }
  > = {
    "New York": { temperature: 2, condition: "Cloudy", humidity: 65 },
    "San Francisco": { temperature: 14, condition: "Sunny", humidity: 70 },
    London: { temperature: 8, condition: "Rainy", humidity: 85 },
    Tokyo: { temperature: 10, condition: "Clear", humidity: 55 },
    Sydney: { temperature: 25, condition: "Sunny", humidity: 60 },
  };

  const data = weatherMap[city];
  if (!data) {
    return { city, temperature: 15, condition: "Unknown", humidity: 50 };
  }
  return { city, ...data };
}

// 3. Register tool: get weather
server.registerTool(
  "get_weather",
  {
    title: "Get Weather",
    description:
      "Get current weather for a city including temperature, condition, and humidity",
    inputSchema: z.object({
      city: z
        .string()
        .describe("City name, e.g. New York, London, Tokyo"),
    }),
  },
  async ({ city }) => {
    const weather = getWeatherData(city);
    const text = `Weather in ${weather.city}: ${weather.condition}, ${weather.temperature}°C, humidity ${weather.humidity}%`;
    return {
      content: [{ type: "text", text }],
    };
  }
);

// 4. Register tool: compare two cities
server.registerTool(
  "compare_weather",
  {
    title: "Compare Weather",
    description: "Compare weather between two cities",
    inputSchema: z.object({
      city1: z.string().describe("First city"),
      city2: z.string().describe("Second city"),
    }),
  },
  async ({ city1, city2 }) => {
    const w1 = getWeatherData(city1);
    const w2 = getWeatherData(city2);
    const diff = w1.temperature - w2.temperature;

    const text = [
      `Weather Comparison: ${w1.city} vs ${w2.city}`,
      `---`,
      `${w1.city}: ${w1.condition}, ${w1.temperature}°C, humidity ${w1.humidity}%`,
      `${w2.city}: ${w2.condition}, ${w2.temperature}°C, humidity ${w2.humidity}%`,
      `---`,
      `Temperature difference: ${Math.abs(diff)}°C (${diff > 0 ? w1.city + " is warmer" : w2.city + " is warmer"})`,
    ].join("\n");

    return {
      content: [{ type: "text", text }],
    };
  }
);

// 5. Start STDIO transport
async function main() {
  const transport = new StdioServerTransport();
  await server.connect(transport);
  console.error("Weather MCP Server started"); // Use stderr, not stdout!
}

main().catch(console.error);

Key concepts in this code:

  • McpServer — Core class where all tools, resources, and prompts are registered
  • registerTool — SDK v2 method taking three arguments: tool name, config object, handler function
  • inputSchema — Zod schema that defines parameter types and descriptions. AI clients use this schema to construct correct tool calls
  • StdioServerTransport — Communicates via stdin/stdout, the standard transport for local MCP servers
  • console.error not console.log — Critical detail explained in the debugging section below

Step 3: Build and Test

Compile TypeScript:

npx tsc
chmod +x dist/index.js

Register with Claude Code:

claude mcp add weather-server node /absolute/path/to/dist/index.js

Now open Claude Code and test:

> What's the weather in Tokyo?

> Compare the weather in New York and London

Claude Code automatically discovers your get_weather and compare_weather tools and calls them.

To verify your server is loaded:

claude mcp list

For more on Claude Code’s MCP integration, see my Claude Code MCP Setup guide.

Adding Resources and Prompts

Beyond tools, MCP servers can expose data and interaction templates.

Registering a Resource

Resources let AI clients read your data. Here’s a resource that exposes a list of supported cities:

server.registerResource(
  "supported-cities",
  "weather://cities",
  {
    title: "Supported Cities",
    description: "Returns all cities with weather data available",
    mimeType: "application/json",
  },
  async (uri) => ({
    contents: [
      {
        uri: uri.href,
        text: JSON.stringify([
          "New York",
          "San Francisco",
          "London",
          "Tokyo",
          "Sydney",
        ]),
      },
    ],
  })
);

Registering a Prompt

Prompts are pre-built interaction templates:

server.registerPrompt(
  "travel-advice",
  {
    title: "Travel Advice",
    description: "Get outfit and travel tips based on destination weather",
    argsSchema: z.object({
      destination: z.string().describe("Destination city"),
    }),
  },
  ({ destination }) => ({
    messages: [
      {
        role: "user" as const,
        content: {
          type: "text" as const,
          text: `Based on the current weather in ${destination}, suggest appropriate clothing and travel tips.`,
        },
      },
    ],
  })
);

Building a Real-World MCP Server: GitHub Issues

Let’s build something more practical — a server that reads GitHub issues. This demonstrates real API integration.

#!/usr/bin/env node

import { McpServer } from "@modelcontextprotocol/server";
import { StdioServerTransport } from "@modelcontextprotocol/server";
import * as z from "zod";

const server = new McpServer({
  name: "github-issues-server",
  version: "1.0.0",
});

// Tool: List recent issues
server.registerTool(
  "list_issues",
  {
    title: "List GitHub Issues",
    description: "List recent issues from a GitHub repository",
    inputSchema: z.object({
      owner: z.string().describe("Repository owner (e.g. 'anthropics')"),
      repo: z.string().describe("Repository name (e.g. 'claude-code')"),
      state: z
        .enum(["open", "closed", "all"])
        .default("open")
        .describe("Issue state filter"),
      limit: z
        .number()
        .min(1)
        .max(30)
        .default(10)
        .describe("Number of issues to return"),
    }),
  },
  async ({ owner, repo, state, limit }) => {
    const url = `https://api.github.com/repos/${owner}/${repo}/issues?state=${state}&per_page=${limit}`;

    const response = await fetch(url, {
      headers: {
        Accept: "application/vnd.github.v3+json",
        "User-Agent": "mcp-github-issues",
      },
    });

    if (!response.ok) {
      return {
        content: [
          {
            type: "text",
            text: `Error fetching issues: ${response.status} ${response.statusText}`,
          },
        ],
        isError: true,
      };
    }

    const issues = await response.json();
    const formatted = issues
      .map(
        (issue: any) =>
          `#${issue.number} [${issue.state}] ${issue.title}\n  Labels: ${issue.labels.map((l: any) => l.name).join(", ") || "none"}\n  Created: ${issue.created_at}\n  URL: ${issue.html_url}`
      )
      .join("\n\n");

    return {
      content: [
        {
          type: "text",
          text: `Issues for ${owner}/${repo} (${state}):\n\n${formatted}`,
        },
      ],
    };
  }
);

// Tool: Get issue details
server.registerTool(
  "get_issue",
  {
    title: "Get Issue Details",
    description: "Get detailed information about a specific GitHub issue",
    inputSchema: z.object({
      owner: z.string().describe("Repository owner"),
      repo: z.string().describe("Repository name"),
      issue_number: z.number().describe("Issue number"),
    }),
  },
  async ({ owner, repo, issue_number }) => {
    const url = `https://api.github.com/repos/${owner}/${repo}/issues/${issue_number}`;

    const response = await fetch(url, {
      headers: {
        Accept: "application/vnd.github.v3+json",
        "User-Agent": "mcp-github-issues",
      },
    });

    if (!response.ok) {
      return {
        content: [
          {
            type: "text",
            text: `Error: ${response.status} ${response.statusText}`,
          },
        ],
        isError: true,
      };
    }

    const issue = await response.json();
    const text = [
      `# #${issue.number}: ${issue.title}`,
      `State: ${issue.state}`,
      `Author: ${issue.user.login}`,
      `Created: ${issue.created_at}`,
      `Labels: ${issue.labels.map((l: any) => l.name).join(", ") || "none"}`,
      `Comments: ${issue.comments}`,
      `---`,
      issue.body || "(no description)",
    ].join("\n");

    return {
      content: [{ type: "text", text }],
    };
  }
);

async function main() {
  const transport = new StdioServerTransport();
  await server.connect(transport);
  console.error("GitHub Issues MCP Server started");
}

main().catch(console.error);

After building and registering this server, you can ask Claude Code:

> List open issues in anthropics/claude-code
> Show me the details of issue #42 in that repo

Debugging MCP Servers

Debugging is the trickiest part of MCP server development. Here are the essential techniques.

Use console.error, Not console.log

This is the #1 mistake new MCP developers make, as noted in the MCP debugging guide. MCP uses STDIO protocol for communication — stdout is the data channel. Any console.log output gets interpreted as protocol messages, breaking communication.

// WRONG — breaks STDIO protocol
console.log("Debug info");

// CORRECT — uses stderr, doesn't interfere
console.error("Debug info");

Use SDK Built-in Logging

MCP SDK v2 provides structured logging that sends messages to the client:

server.registerTool(
  "fetch-data",
  {
    description: "Fetch data from URL",
    inputSchema: z.object({ url: z.string() }),
  },
  async ({ url }, ctx) => {
    await ctx.mcpReq.log("info", `Fetching ${url}`);
    const res = await fetch(url);
    await ctx.mcpReq.log("debug", `Response status: ${res.status}`);
    const text = await res.text();
    return { content: [{ type: "text", text }] };
  }
);

Enable logging when creating the server:

const server = new McpServer(
  { name: "my-server", version: "1.0.0" },
  { capabilities: { logging: {} } }
);

Common Errors and Fixes

SymptomCauseFix
Server won’t startMissing "type": "module" in package.jsonAdd "type": "module"
Tools not recognizedInvalid inputSchema formatWrap with z.object()
Communication errorsUsing console.logSwitch to console.error
Type errorsSDK version mismatchVerify @modelcontextprotocol/server v2
Tool calls return nothingMissing content in responseEnsure handler returns { content: [...] }
Server crashes on startupUnhandled async errorAdd .catch(console.error) to main()
Parameters not validatedUsing raw object instead of ZodAlways use z.object() with .describe()

Restart and Verify

# Check registered servers
claude mcp list

# Remove and re-add (restart the server)
claude mcp remove weather-server
claude mcp add weather-server node /path/to/dist/index.js

Publishing Your MCP Server

When your server is ready, publish it to npm so others can use it.

Prepare package.json

{
  "name": "@your-scope/weather-mcp-server",
  "version": "1.0.0",
  "description": "MCP server for weather data queries",
  "type": "module",
  "bin": {
    "weather-mcp-server": "./dist/index.js"
  },
  "files": ["dist"],
  "keywords": ["mcp", "mcp-server", "weather"],
  "license": "MIT"
}

Build and Publish

npm run build
npm publish --access public

After publishing, anyone can use your server with one command:

claude mcp add weather-server npx @your-scope/weather-mcp-server

Share with the Community

Submit your project to the awesome-mcp-servers repository to increase visibility. You can also list it on the MCP official server registry.

Project Structure Best Practices

For larger MCP server projects, organize your code like this:

my-mcp-server/
├── src/
│   ├── index.ts          # Entry point, server setup
│   ├── tools/            # Tool handlers
│   │   ├── query.ts
│   │   └── mutate.ts
│   ├── resources/        # Resource handlers
│   │   └── config.ts
│   └── utils/            # Shared utilities
│       └── api-client.ts
├── dist/                 # Compiled output
├── package.json
├── tsconfig.json
└── README.md

Key principles:

  • One domain per server — Don’t build a mega-server with 50 tools. Create focused servers (3-10 tools each)
  • Separate tool handlers — Keep each tool’s logic in its own file for testability
  • Type your responses — Use TypeScript interfaces for API responses to catch errors at compile time
  • Handle errors gracefully — Return isError: true in content rather than throwing exceptions

FAQ

What programming languages can I use to build MCP servers?

The MCP protocol has official SDKs for TypeScript, Python, and C#. TypeScript is the most mature with the best documentation. Python is a strong alternative. You can also build servers in any language that supports JSON-RPC 2.0 over STDIO or HTTP.

How is an MCP server different from a REST API?

MCP servers use JSON-RPC 2.0 instead of HTTP REST. The key difference is standardized tool discovery — AI clients can automatically list all available tools and their parameters without reading documentation. MCP also supports STDIO transport, running as a local process without an HTTP server.

Can MCP servers work with clients other than Claude Code?

Yes. Any MCP-compatible client can use your server, including Cursor, VS Code with Copilot extensions, Continue, and other AI tools. This is the core benefit of building on an open protocol — build once, use everywhere.

What is the difference between MCP SDK v1 and v2?

SDK v2 split the package into @modelcontextprotocol/server and @modelcontextprotocol/client. Tool registration changed from server.tool() to server.registerTool(). Input validation now requires z.object() wrapping. If a tutorial uses server.tool(), it’s using v1 syntax.

How many tools should one MCP server have?

The protocol has no limit, but practically, 3-10 tools per server works best. Too many tools reduces the AI’s accuracy in selecting the right one. Group related tools in a single server, and create separate servers for different domains.

Can MCP servers access the internet?

Yes. Your server runs as a Node.js process with full network access. You can call external APIs, query databases, read files — anything Node.js can do. Just be mindful of latency, as the AI client waits for your tool to respond.

Summary

Building MCP servers follows a straightforward workflow:

  1. Initialize — Set up a TypeScript project with @modelcontextprotocol/server and zod
  2. Register tools — Use server.registerTool() with Zod schemas for input validation
  3. Test locally — claude mcp add for instant testing in Claude Code
  4. Debug — Use console.error (never console.log), check common errors table
  5. Publish — npm publish and share via npx

The MCP ecosystem is growing fast. Every MCP server you build becomes instantly usable by Claude Code, Cursor, Copilot, and any future MCP-compatible tool. Start building today.

Comments

Join the discussion — requires a GitHub account
